| Certifications/认证 | TUV |
Certificate No./证书号码 | R 50277846 |
Rated Voltage /额定电汪 | 1000VDC |
Ambient Temperature Range /温度范图 | -40℃~+85℃ |
Safety Class/安全等级 | Class Ⅱ/Ⅱ级 |
Protection Degree /保护等级 | IP67 |
Wire Size Range /线缆尺寸范围 | 4mm² |
Flame Resistance /阻燃等级 | 5VA |
| Waterproof Structure /防水结构 | Potting Sealant/灌封胶 |
| Volume Of Potting Glue /灌胶量 | Appr.35ml/约35ml |
| width Of Ribbons /汇流条宽度 | Up to 8mm/***大8mm |
| Centerline Spacing Between Terminals /端口间距 | 20mm |
| Connection Method /汇流条连接方式 | Soldering/焊接 |
| Insulation Material/绝缘材料 | PPO |
| Contact Material /接触材料 | Copper, Tin-Plated/铜,镀锡 |
| Overall Size/外形尺寸 | 118*72.5*15.7mm |
| Optional Cannedor/可选配连接器 | PV-GZX0601-1,MC4, H4 |
