| 化学类型 | 铅酸蓄电池 |
|---|---|
| 电压 | 12（V） |
| 类型 | 储能用蓄电池 |
| 荷电状态 | 免维护蓄电池 |
| 电池盖和排气拴结构 | 阀控式密闭蓄电池 |
| 额定容量 | 7AH~200AH |
| 外型尺寸 | 340*176*255（mm） |
| 产品认证 | CCC |
| 适用范围 | ups蓄电池 |
| 品牌 | 鹏晟达 |
| 型号 | LC-P-12100 |
LC-P系列---后备浮充使用长寿命品 |
型 号 | 电压(V) | 容量(Ah) | 外型尺寸(mm) | 端子型号 | 单重 | |||
长(L) | 宽(W) | 高(H) | 总高(TH) | |||||
LC-P061R3 | 6 | 1.3 | 97 | 24 | 50 | 55 | 187 | 0.25 |
LC-P067R2 | 6 | 7.2 | 151 | 34 | 94 | 100 | 187& 250 | 1.30 |
LC-P0612 | 6 | 12 | 151 | 50 | 94 | 100 | 187& 250M | 2.00 |
LC-P06200 | 6 | 200 | 407 | 173 | 210 | 250 | M10 T | 33.5 |
LC-P121R3 | 12 | 1.3 | 97 | 47.5 | 50 | 55 | 187 | 0.55 |
LC-P122R2 | 12 | 2.2 | 177 | 34 | 60 | 66 | 187 | 0.80 |
LC-P123R4 | 12 | 3.4 | 134 | 67 | 60 | 66 | 187 | 1.20 |
LC-P127R2 | 12 | 7.2 | 151 | 64.5 | 94 | 100 | 187& 250M | 2.50 |
LC-PA1212 | 12 | 12 | 151 | 98 | 94 | 100 | 187& 250M | 3.65 |
LC-PA1216 | 12 | 16 | 151 | 98 | 99 | 105 | 187& 250M | 4.10 |
LC-PD1217 | 12 | 17 | 181 | 76 | 167 | 167 | M5 L& M5 A | 5.45 |
LC-P1220 | 12 | 20 | 181 | 76 | 167 | 167 | M5 L& M5 A | 5.80 |
LC-P1224 | 12 | 24 | 165 | 125 | 175 | 179.5/175 | M5 L& M5 A | 8.05 |
LC-P1228 | 12 | 28 | 165 | 125 | 175 | 179.5/175 | M5 L& M5 A | 9.40 |
LC-P1238 | 12 | 38 | 197 | 165 | 175 | 180/175 | M6 L& M5 A | 12.5 |
LC-P1242 | 12 | 42 | 197 | 165 | 175 | 180/175 | M6 L& M5 A | 13.5 |
LC-P1265 | 12 | 65 | 350 | 166 | 175 | 175 | M6 L | 19.0 |
LC-P1275 | 12 | 75 | 350 | 166 | 175 | 175 | M6 L | 21.5 |
LC-P12100 | 12 | 100 | 407 | 173 | 210 | 236 | M8 L | 29.0 |
LC-PB12100 | 12 | 100 | 407 | 173 | 210 | 236 | M8 L | 36.5 |
LC-P12120 | 12 | 120 | 407 | 173 | 210 | 236 | M8 L | 34.5 |
LC-P12150 | 12 | 150 | 532.4 | 183.3 | 209 | 235/214 | M8嵌入式铜芯 | 45.0 |
LC-P12200 | 12 | 200 | 533 | 236.5 | 211 | 237/216 | M8嵌入式铜芯 | 56.0 |
